Anhang
•
Volume (CC 7)
Message which controls the sections volume.
Data format: BnH 07H vvH
n=channel number
vv=volume value
•
Expression (CC 11)
Message which controls the sections expression.
Data format: BnH 0BH vvH
n=channel number
vv=expression value
•
Bank Select LSB (CC 32)
Controller transmitted in combination of Program
Change and Bank Select MSB in order to select a
specific bank of sound. It can be transmitted using
the PRG IN COMBIN. function and when stored in the
combinations and Tutti.
Data format: BnH 20H vvH
n=channel number
vv=bank LSB number
•
Sustain (CC 64)
Message which controls the Sustain effect.
Data format: BnH 40H vvH
n=channel number
vv=switch
•
All Sounds Off (CC 120)
Terminates all voices currently on for the specific
channel.
Data format: BnH 78H 00H
n=channel number
•
Reset All Controllers (CC 121)
Controllers are set to the default value.
Data format: BnH 79H 00H
n=channel number
-
This message is transmitted only.
•
All Notes Off (CC 123)
Terminates all notes currently on for the specific
channel.
Data format: BnH 7BH 00H
n=channel number
Referenzhandbuch
:0H–EH (1–15)
:00H–7FH (0–127)
:0H–EH (1–15)
:00H–7FH (0–127)
:0H–EH (1–15)
:00H–7FH (0–127)
:0H–EH (1–15)
:00H (0) off
(received as 00H-39H)
:7FH (127) on
(received as 40H-7FH)
:0H-EH (1–15)
:0H–EH (1–15)
:0H–EH (1–15)
Program Change
Messages
for
programs in external modules. It also can be
received by the organ to recall combinations, Tutti
and Crescendo steps.
Data format: CnH mmH
Transmitted:
n=channel number
mm=Program Ch. number:00H–7FH (0–127)
Received:
n=channel number
mm=Program Ch. number:
00H (0): general HR
01H-0CH (1-12): general combinations 1-12
60H (96): Tutti OFF
61H (97): Tutti ON
62H(98)(3,4-manual models): Man.II Plenum OFF
63H(99)(3,4-manual models): Man.II Plenum ON
62H(98)(2-manual models): Man.I Plenum OFF
63H(99)(2-manual models): Man.I Plenum ON
64H(100)(3,4-manual models):Man.III Plenum OFF
65H(101)(3,4-manual models):Man.III Plenum ON
64H(100)(2-manual models): Man.II Plenum OFF
65H(101)(2-manual models): Man.II Plenum ON
66H(102)(3,4-manual models): Man.I Plenum OFF
67H(103)(3,4-manual models): Man.I Plenum ON
68H (104): Man.IV Plenum OFF
69H (105): Man.IV Plenum ON
6AH (106): Plenum OFF
6BH (107): Plenum ON
6CH (108): Reed OFF
6DH (109): Reed ON
6FH (111): Crescendo — (OFF)
70H–7FH (112-127): Crescendo steps 1-16
STANDARD SYSTEM EXCLUSIVE MESSAGES
•
Device Inquiry
Instrument information sent after switching on and
when a Device Inquiry Request is received.
Data format: F0H 7EH 00H 06H 02H 31H ffH
ffH mmH mmH xxH yyH zzH vvH F7H
F0H: Exclusive status
7EH: Universal Non Realtime message
00H: channel
06H: general information
02H: device ID reply
31H: Viscount ID
ffH ffH: device family code
mmH mmH: device family member code
xxH yyH zzH vvH: software version
F7H: End of Exclusive
•
Master Fine Tuning
Parameter: Tuning
Video page: Tuning
Data format: F0H 7FH 7FH 04H 03H vvH nnH
F7H
F0H: Exclusive status
7FH: Universal Realtime message
7FH: channel (any)
DE - 64
selecting
sounds,
timbres
:0H–EH (1–15)
:FH (16)
or
