Pitch
Parameter: Pitch
Video page: Tuning
Data format: F0H 31H 2FH 67H 00H 0nH 0nH
0nH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
67H : pitch
0nH 0nH 0nH: nibblezed data of pitch value
00H 01H 08H: A=415,30 Hz
04H 00H 00H: A=440 Hz
07H 0EH 08H: A=466,16 Hz
F7H: End of Exclusive
•
Cancel
Data format: F0H 31H 2FH 6CH 00H F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
6CH : cancel
00H : execute cancel
F7H: End of Exclusive
•
Couplers (3 and 4 manuals organ models)
Data format: F0H 31H 2FH 70H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
vvH: type and switch
00H=III/P or SW/P on
10H=III/P or SW/P off
01H=II/P or HW/P on
11H=II/P or HW /P off
02H=I/P or PO/P on
12H=I/P or PO/P off
03H=III/II or SW/HW on
13H=III/II or SW/HW off
04H=I/II or PO/HW on
14H=I/II or PO/HW off
05H=III/I or SW/PO on
15H=III/I or SW/PO off
F7H: EOX
-
This message is received only.
Data format: F0H 31H 2FH 70H 7FH vvH nnH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
7FH: other coupler
vvH nnH:type and switch
04H 21H:IV/P or SO/P on
04H 20H:IV/P or SO/P off
14H 21H:IV/II or SO/HW on
14H 20H:IV/II or SO/HW off
24H 21H:IV/III or SO/SW on
24H 20H:IV/III or SO/SW off
34H 21H:IV/I or SO/PO on
34H 20H:IV/I or SO/PO off
F7H: End of Exclusive
-
This message is received only.
Referenzhandbuch
•
Couplers (2 manuals organ models)
Data format: F0H 31H 2FH 70H vvH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
vvH: type and switch
00H=II/P or SW/P on
10H=II/P or SW/P off
01H=I/P or HW/P on
11H=I/P or HW/P off
03H=II/I or SW/HW on
13H=II/I or SW/HW off
F7H: End of Exclusive
-
This message is received only.
•
Sub- and super-octave
Data format: F0H 31H 2FH 70H 7FH vvH ssH F7H
F0H: Exclusive status
31H: Viscount ID
2FH: system control
70H: coupler
7FH: other coupler
vvH ssH:type and switch
02H 31H=Super Octave III/P or SW/P on
02H 30H=Super Octave III/P or SW/P off
03H 31H=Super Octave I/P or PO/P on
03H 30H=Super Octave I/P or PO/P off
04H 31H=Super Octave IV/P or SO/P on
04H 30H=Super Octave IV/P or SO/P off
22H 11H=Sub Octave III or SW on
22H 10H=Sub Octave III or SW off
22H 21H=Unison Off III or SW on
22H 20H=Unison Off III or SW off
22H 31H=Super Octave III or SW on
22H 30H=Super Octave III or SW off
12H 11H=Sub Octave III/II or SW/HW on
12H 10H=Sub Octave III/II or SW/HW off
12H 31H=Super Octave III/II or SW/HW on
12H 30H=Super Octave III/II or SW/HW off
13H 11H=Sub Octave I/II or PO/HW on
13H 10H=Sub Octave I/II or PO/HW off
13H 31H=Super Octave I/II or PO/HW on
13H 30H=Super Octave I/II or PO/HW off
14H 11H=Sub Octave IV/II or SO/HW on
14H 10H=Sub Octave IV/II or SO/HW off
14H 31H=Super Octave IV/II or SO/HW on
14H 30H=Super Octave IV/II or SO/HW off
32H 11H=Sub Octave III/I or SW/PO on
32H 10H=Sub Octave III/I or SW/PO off
32H 31H=Super Octave III/I or SW/PO on
32H 30H=Super Octave III/I or SW/PO off
33H 11H=Sub Octave I or PO on
33H 10H=Sub Octave I or PO off
34H 11H=Sub Octave IV/I or SO/PO on
34H 10H=Sub Octave IV/I or SO/PO off
34H 31H=Super Octave IV/I or SO/PO on
34H 30H=Super Octave IV/I or SO/PO o
F7H: End of Exclusive
DE - 66
