PACKAGES
a
d
a2
Fig. 4
REF VK52
PARENCHYMAL PROBE GUIDE
Packaged in a sterile double tray. When REF
VK52 is supplied as kit with REF CC1P1 this kit
is protected by an outer plastic bag.
This outer plastic bag is non-sterile. It serves
to protect the inner packages from moisture
during shipping and storage.
Please remove and discard the plastic bag
prior to use.
a Parenchymal Probe Guide,
length 415 mm, Ø = 2.8 mm,
with suture rings Ø = 4 mm
a1 Trocar, attached l = 150 mm,
Ø = 3.2 mm
a2 Connector for oxygen probe
(Ø <1.4 mm)
b Drill bit (Ø 5.3 mm)
c Hex wrench for adjustment of the drill stop
d Adjustable drill stop with set screw
c
b
a1
d
a
c
Fig. 5
REF CC1P1
COMBINED OXYGEN AND TEMPERATURE
PROBE
For Oxygen Pressure (p
Cerebral Tissue.
Packaged in a sterile double tray protected by
an outer plastic bag.
This outer plastic bag is non-sterile. It serves
to protect the inner packages from moisture
during shipping and storage.
Please remove and discard the plastic bag
prior to use.
The probe (length 462 mm) [c, d, e] is delivered
(as shown on the right [a, b]) in a closed protection
tube [b], which provides mechanical protection
and protects the probe from drying out. The
calibration data for the probe are electronically
stored on a smart card [g]. Probe and smart card
have the same number. The extension tube [d]
serves to connect the probe to the introducer
system. The probe is connected at the rear end
[c] of its plug to the probe cable REF PMOCAB.
At [e] the probe has its p
approximately 18 mm
probe has its temperature sensitive area of
approximately 23 mm
protection tube must be removed at [a] before
use.
g
b
f
e
O ) Monitoring in
bt 2
O sensitive area of
bt 2
(Ø 0.65 mm). At [f] the
2
(Ø 1.3 mm). The entire
2
