Start of the error code
Rapid flashing ...start of the error code output
(2)
Type of error
First slow pulse ... Type of error
(3)
Error location
Second slow pulse
Error ar-
Error code
gument
steady,
0 pulses
continuous
flashing
1 pulse
0 pulses
1 pulse
2 pulses
2 pulses
0 pulses
n pulses
(n>0)
3 pulses
0 pulses
4 pulses
0 pulses
n pulses
5 pulses
n pulses
Cause
Problems with electro-
magnetic compatibility
(EMC)
EEPROM check sum
error
Inline code buffer
overflow. Too many
entries in the table
Unknown data type
programmed configu-
ration incorrect table
entry/bus coupler
(Terminal n) table
comparison incorrect
Terminal bus com-
mand error
Terminal bus data er-
ror
Break behind termi-
nals (0:coupler)
Terminal bus error du-
ring register communi-
cation with terminals
Remedy
Check power supply for
extremes in undervoltage
or overvoltage
Carry out EMC measures
If there is a K bus error,
the error can be localised
by restarting the field bus
coupler (switching it off
and on again)
Set manufacturer's setting
with the KS2000
Attach fewer terminals
Update field bus coupler
software
Check that programmed
configuration is correct
Incorrect table entry/bus
coupler
No terminal inserted, at-
tach terminal
A terminal is faulty; Dis-
connect half the terminals
and check whether the er-
ror occurs with the remai-
ning terminals. Continue
this process until the faul-
ty terminal is found
Check whether the n+1
terminal is correctly con-
nected, and change if ne-
cessary
Check whether the end
terminal KL9010 is con-
nected
Change terminals
