General
Safety
Danger from incorrect operation and work that is not carried out properly.
This can result in serious personal injury and damage to property.
▶
▶
▶
▶
Machine concept
The interface DPS 2500 Profibus is an interface for connection of the plasma
power source DPS 2500 to a robot control. The input and output signals are
transmitted via a profibus-dataline between the interface and the robot control.
The Profibus DPS 2500 interface is already fitted on the power source and con-
nected. It is only necessary to connect the data line and the mains cable to the
interface.
IMPORTANT! To avoid any malfunctions the length of the data line between the
interface and the robot control should be kept as short as possible.
Connections to
the interface
WARNING!
All the work and functions described in this document must only be carried
out by technically trained and qualified personnel.
Read and understand this document in full.
Read and understand all safety rules and user documentation for this device
and all system components.
Read and understand all Operating Instructions for the complete system.
(4)
(3)
(2)
(1)
Mains lead cleat
for providing the profibus data
line and the power supply for
the fieldbus coupler
LocalNet connection with ter-
(2)
minating plug
for software updates and dia-
gnosis
(3)
Protective conductor contact
for connection of additional op-
tions to the power source pro-
tective conductor (e.g. mobile
(1)
wagon, arc switch off box, etc.)
(4)
Plug of the mains cable
for connecting the power
source on the mains 400 V.
