RxD/TxD-P (3)
DGND (5)
RxD/TxD-N (8)
Parallelschaltung von Stromquellen
Connecting the
mains cable to
the mains plug
Mains cable plug assignment
Stromquelle 1
Hutschiene
L1 L2 L3
Stromquelle 2
Abschirmung
Hutschiene
The interface and power source are de-
signed to run on the mains voltage sta-
ted on the rating plate.
If your version of the appliance does
not come with mains cables and plugs
ready-fitted, these must be fitted in
accordance with national regulations
and standards.
For details of fuse protection of the
mains lead, please see the technical
data.
CAUTION!
Inadequately dimensioned electrical
installations can cause serious dama-
ge.
The mains plug, mains lead and their
fuse protection must be rated accord-
ingly.
RxD/TxD-P (3)
DGND (5)
RxD/TxD-N (8)
