MICRO-EPSILON induSENSOR MSC 7210 Betriebsanleitung Seite 41

Installation and Assembly
Fig. 6 Dimensional drawing LDR - x - SA, dimensions in mm
(inches), not to scale
Fig. 7 Dimensional drawing LDR - x - CA, dimensions in
mm (inches), not to scale
Plunger in start of measuring range
1)
induSENSOR MSC 7210
All manuals and user guides at all-guides.com
7 A
(.28)
Plunger
6 B
(.24)
Plunger
ø5 appr. 24 (.94)
(.20)
25 (.98)
1)
10
(.39)
25 (.98)
1)
30 (1.18)
Leads
Dimension A
LDR-10-SA 47 (1.85)
LDR-25-SA 73 (2.87)
LDR-50-SA 127 (5.00)
Dimension B
LDR-10-CA 41 (1.61)
LDR-25-CA 67 (2.64)
LDR-50-CA 121 (4.76)
Bending radius
sensor cable
C7210-x for
LDR-x-SA:
8 mm (once)
15 mm (conti-
nuous)
Bending
radius sensor
cable C7210-x
for LDR-x-CA:
10 mm (once)
30 mm (conti-
nuous)
Page 41
