Installation and Assembly
4.4
The power supply/output cable PC710-6/4 (available as an option) has a bend radius of 24 mm (minimum).
All the connections for power supply / sensors / signal output are located on the controller, see
Fig.
Cable characteristics
Outer diameter cable:
Wire:
Wiring
The integral cable for LDR-x-CA sensors is ready to use.
induSENSOR MSC 7210
All manuals and user guides at all-guides.com

Power Supply, Sensor and Signal Output

10.
3.0 ... 5.0 mm (AWG 8 ... 4)
0.08 ... 0.25 mm² (AWG 28 ... 24)
Open the housing in order to connect the sensors and wire the output and supply cable.
Undo the screws.
Pass the sensor and signal cables through the cable glands, see
Unisolate the leads, press wire-end sleeves on the leads and the screening. Use proper crimpers.
Assemble the unit and tighten the screws.
Fig.
Fig. 8.
9, see
