Tritec TRI-STAND Montageanleitung Seite 157

Maximum
Module Type
power
pmax <w>
CS3k-280MS 280
CS3k-285MS 285
CS3k-290MS 290
CS3k-295MS
295
CS3k-300MS 300
CS3k-305MS
305
CS3k-310MS 310
CS3k-315MS
315
CS3k-320MS 320
CS3k-325MS 325
CS3k-330MS 330
CS3k-250p 250
CS3k-255p 255
CS3k-260p 260
CS3k-265p
265
CS3k-270p 270
CS3k-275p
275
CS3k-280p 280
CS3k-285p
285
CS3k-290p 290
CS3k-295p
295
CS3k-300p 300
CS3k-305p
305
CS3k-310p 310
CS3k-315p 315
CS3k-320p 320
CS3k-325p 325
CS3k-330p 330
CS3k-335p 335
CS3k-340p
340
CS3k-345p 345
CS3k-350p
350
CS1v-240MS 240
CS1v-245MS
245
CS1v-250MS 250
CS1v-255MS
255
CS1v-260MS 260
CS1v-265MS
265
CS1v-270MS 270
CS1v-275MS
275
CS1v-280MS 280
CS1v-285MS 285
CS1vL-190MS 190
CS1vL-195MS 195
CS1vL-200MS 200
Open
Operating Operating
Circuit
voltage current
voltage
vmp <v> Imp <A>
voc <v>
31.7 8.84 38.5
31.9 8.94 38.7
32.1 9.04 38.9
32.3 9.14 39.1
32.5 9.24 39.3
32.7 9.33 39.5
32.9 9.43 39.7
33.1 9.52 39.9
33.3 9.61 40.1
33.5 9.71 40.3
33.7 9.8 40.5
30 8.34 36.7
30.2 8.45 36.9
30.4 8.56 37.1
30.6 8.66 37.3
30.8 8.77 37.5
31 8.88 37.7
31.2 8.98 37.9
31.4 9.08 38.1
32.3 8.98 38.9
32.5 9.08 39.1
32.7 9.18 39.3
32.9 9.28 39.5
33.1 9.37 39.7
33.3 9.46 39.9
33.5 9.56 40.1
33.7 9.65 40.3
33.9 9.74 40.5
34.1 9.83 40.7
34.3 9.92 40.9
34.5 10 41.1
34.7 10.09 41.3
28.3 8.48 34.7
28.6 8.58 34.9
28.8 8.68 35.1
29.0 8.79 35.3
29.2 8.89 35.5
29.4 9.00 35.7
29.6 9.11 35.9
29.8 9.22 36.1
30.0 9.33 36.3
30.2 9.44 36.5
22.5 8.45 27.6
22.7 8.58 27.8
22.9 8.73 28.0
Short
Max. Series Overall
Circuit
Fuse Dimension
Current
Rating <A>
Isc <A>
9.49 30
9.57 30
9.65 30
9.73 30
1675 x 992 x 40
9.82 30
9.9 30
(65.9 ˣ 39.1 ˣ
9.98 30
1.57 / 1.38 in)
10.06 30
10.14 30
10.22 30
10.3 30
8.98 30
9.06 30
9.14 30
9.22 30
9.3 30
9.38 30
9.47 30
9.56 30
9.49 30
1675 x 992 x 40
9.57 30
9.65 30
(65.9 ˣ 39.1 ˣ
9.73 30
1.57 / 1.38 in)
9.81 30
9.89 30
9.97 30
10.05 30
10.13 30
10.21 30
10.29 30
10.37 30
10.45 30
9.15 15
9.22 15
9.29 15
9.37 15
1638x826x40
9.44 15
(64.5 x 32.5 x
9.51 15
1.57 in)
9.59 15
9.66 15
9.74 15
9.82 15
9.10 15
1322×826×35
9.22 15 (52.05 x 32.5 x
1.38 in)
9.34 15
| 27
weight
<kg>
<mm>
/ 35 18.5
(40.8 lbs)
/ 35 18.5
(40.8 lbs)
15.4
(34.0 lbs)
12.6
(27.8 lbs)
www.canadiansolar.com
