eNGiNeeriNG DrawiNG (mm)
rear View
180
6-Φ5
Grounding
Hole
8-14x9
Mounting
Hole
1007
40 1048
eleCTriCal DaTa | STC*
CS3l
Nominal Max. Power (Pmax)
Opt. Operating Voltage (Vmp) 32.2 V
Opt. Operating Current (Imp) 10.24 A 10.34 A 10.43 A 10.52 A
Open Circuit Voltage (Voc)
Short Circuit Current (Isc)
Module Efficiency
Operating Temperature
Max. System Voltage
Module Fire Performance
Max. Series Fuse Rating
Application Classification
Power Tolerance
* Under Standard Test Conditions (STC) of irradiance of 1000 W/m
and cell temperature of 25°C.
eleCTriCal DaTa | NmoT*
CS3l
Nominal Max. Power (Pmax)
Opt. Operating Voltage (Vmp) 29.4 V
Opt. Operating Current (Imp) 8.34 A
Open Circuit Voltage (Voc)
Short Circuit Current (Isc)
* Under Nominal Module Operating Temperature (NMOT), irradiance of 800 W/m
spectrum AM 1.5, ambient temperature 20°C, wind speed 1 m/s.
* The specifications and key features contained in this datasheet may deviate slightly
from our actual products due to the on-going innovation and product enhancement.
Canadian Solar Inc. reserves the right to make necessary adjustment to the information
described herein at any time without further notice.
Please be kindly advised that PV modules should be handled and installed by qualified
people who have professional skills and please carefully read the safety and installation
instructions before using our PV modules.
CaNaDiaN Solar iNC.
545 Speedvale Avenue West, Guelph, Ontario N1K 1E6, Canada, www.canadiansolar.com, support@canadiansolar.com
Frame Cross Section a-a
30
11
mounting Hole
A
A
9
330p 335p 340p 345p
330 W 335 W 340 W 345 W
32.4 V 32.6 V 32.8 V
39.2 V 39.4 V 39.6 V 39.8 V
10.82 A 10.90 A 10.98 A 11.06 A
17.84% 18.11% 18.38% 18.65%
-40°C ~ +85°C
1500V (IEC/UL) or 1000V (IEC/UL)
TYPE 1 (UL 1703) or
CLASS C (IEC 61730)
20 A
Class A
0 ~ + 5 W
, spectrum AM 1.5
2
330p 335p 340p 345p
245 W 249 W 252 W 256 W
29.6 V 29.7 V 29.9 V
8.42 A 8.50 A 8.57 A
36.7 V 36.9 V 37.1 V 37.3 V
8.73 A 8.79 A 8.85 A 8.91 A
CS3l-330p / i-V CUrVeS
a
11
10
9
8
7
6
5
4
3
2
1
0
R
5 10 15 20 25 30 35 40 45
1000 W/m
2
800 W/m
2
600 W/m
2
400 W/m
2
200 W/m 2
meCHaNiCal DaTa
Specification
Cell Type
Cell Arrangement
Dimensions
Weight
Front Cover
Frame
J-Box
Cable
Cable Length
(Including Connector)
Connector
Per Pallet
Per Container (40' HQ)
* For detailed information, please contact your local Canadian Solar sales and
technical representatives.
TemperaTUre CHaraCTeriSTiCS
Specification
Temperature Coefficient (Pmax)
Temperature Coefficient (Voc)
Temperature Coefficient (Isc)
2,
Nominal Module Operating Temperature
parTNer SeCTioN
January 2018. All rights reserved, PV Module Product Datasheet V5.571_EN
a
11
10
9
8
7
6
5
4
3
2
1
0
V
5 10 15 20 25 30 35 40 45 50
Data
Poly-crystalline
120 [2 X (10 X 6) ]
1765 X 1048 X 40 mm
(69.5 X 41.3 X 1.57 in)
20.6 kg (45.4 lbs)
3.2 mm tempered glass
Anodized aluminium alloy
IP68, 3 bypass diodes
4.0 mm² (IEC), 12 AWG (UL)
Portrait: 500 mm (19.7 in) (+) / 350 mm
(13.8 in) (-); landscape: 1250 mm (49.2
in)*
T4 series
27 pieces
702 pieces
Data
-0.37 % / °C
-0.29 % / °C
0.05 % / °C
42 ± 3°C
V
5°C
25°C
45°C
65°C
