Electrical installation
Important information for the problem-free functioning of
the device:
• The installation must not cause back pressure to build up.
• Select a hose for the connection with an adequate
cross-section.
• The exhaust air line must be designed in such a way that
no water or other liquid can get into the device through
the exhaust air port.
Fig. 7: Pneumatic connection
Caution: (Exhaust air concept):
In compliance with protection class IP67, an exhaust air line
must be installed in the dry area.
Type 8696
Pilot air port
(label: 1)
Exhaust air port
(label: 3)
9. elecTrical insTallaTion
9.1. safety instructions
Danger!
risk of electric shock!
• Before reaching into the system, switch off the power supply
and secure to prevent reactivation!
• Observe applicable accident prevention and safety regulations
for electrical equipment!
Warning!
risk of injury from improper installation!
• Installation may be carried out by authorized technicians only
and with the appropriate tools!
risk of injury from unintentional activation of the system and
an uncontrolled restart!
• Secure system from unintentional activation.
• Following installation, ensure a controlled restart.
