Inbetriebnahme IDENTControl Compact IC-KP2-2HB17-2V1D
mit PROFINET Protokoll an Siemens S7 Steuerung
10 Tabelle Datenträger
Name TagType Zugriff
IPC02 W#16#3032 Read Fixcode
IPC03 W#16#3033 Read Fixcode
Read Words
Write Words
IPC11 W#16#3131 Read Fixcode
Write Fixcode
IPC12 W#16#3132 Read Fixcode
Read Words
Write Words
IUC72 W#16#3830 Read Fixcode
Write Fixcode
Read Word
Write Words
Read Special Fixcode
Write Special Fixcode
IUC73 W#16#3830 Read Fixcode
Read Special Fixcode
IUC74 W#16#3830 Read Fixcode
Write Fixcode
Read Words
Write Words
Read Special Fixcode
Write Special Fixcode
IUC75 W#16#3830 Read Special Fixcode
IUC80 W#16#3830 Read Fixcode
Write Fixcode
Read Words
Write Words
Read Special Fixcode
Write Special Fixcode
IQC21 W#16#3231 Read Fixcode
Read Words
Write Words
IQC22 W#16#3232 Read Fixcode
Read Words
Write Words
IQC23 W#16#3233 Read Fixcode
Read Words
Write Words
IQC24 W#16#3234 Read Fixcode
Read Words
Write Words
IQC31 W#16#3331 Read Fixcode
Read Words
Write Words
IQC33 W#16#3333 Read Fixcode
Read Words
Write Words
Fixcode Daten Word Address Frequenz
5 Byte - -
4 Byte 116 Byte 0000...001C
5 Byte - -
4 Byte 8192 Byte 0000...07FF
8 Byte 64 Byte
8 Byte - -
8 Byte 28 Byte
96 Byte - -
- - -
8 Byte 112 Byte 0000...001B
8 Byte 256 Byte 0000...003F
8 Byte 224 Byte 0000...0037
8 Byte 928 Byte 0000...00E7
8 Byte 32 Byte 0000...0007
8 Byte 2000 Byte 0000...00F9
125kHz
125kHz
125kHz
125kHz
865 ... 868 MHz
868 MHz
865 ... 871 MHz
868 MHz
868 MHz
13,56MHz
13,56MHz
13,56MHz
13,56MHz
13,56MHz
13,56MHz
