5.13.2.12. Effect Library Bulk Dump Request
Format
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0010nnnn 2n
FORMAT No. 01111110 7E
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000011 43
00110111 37
00110101 35
DATA NAME 01000101 45
0mmmmmmm mm
EOX 11110111 F7
5.13.2.13. Channel Library Bulk Dump Format
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0000nnnn 0n
FORMAT No. 01111110 7E
BYTE COUNT 00000001 01
(HIGH)
BYTE COUNT 01100010 62
(LOW)
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000011 43
00110111 37
00110101 35
DATA NAME 01001000 48
0mmmmmmm mm
DATA 0ddddddd ds
0ddddddd de
CHECK SUM 0eeeeeee ee
EOX 11110111 F7
All data is divided into 4 bit units.
5.13.2.14. Channel Library Bulk Dump Request
Format
STATUS 11110000 F0
ID No. 01000011 43
SUB STATUS 0010nnnn 2n
FORMAT No. 01111110 7E
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000011 43
00110111 37
00110101 35
DATA NAME 01001000 48
0mmmmmmm mm
EOX 11110111 F7
210
System Exclusive Message
Manufacturer's ID (YAMAHA)
n=0-15(MIDI Channel No.1-16)
Universal Bulk Dump
'L'
'M'
' '
' '
'8'
'C'
'7'
'5'
'E'
m= 0-127 (Effect Library No.1-128)
End Of Exclusive
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(MIDI Channel No.1-16)
Universal Bulk Dump
226(216+10)bytes
'L'
'M'
' '
' '
'8'
'C'
'7'
'5'
'H'
m= 0-64 (Channel Library No.0-64)
Receive is effective No.2-64
Effect Library Memory(108*2 bytes)
: :
ee=(INVERT('L'+'M'+...+ds+...+de)+1) AND
7Fh
End Of Exclusive
System Exclusive Message
Manufacturer's ID (YAMAHA)
n=0-15(MIDI Channel No.1-16)
Universal Bulk Dump
'L'
'M'
' '
' '
'8'
'C'
'7'
'5'
'H'
m= 0-64 (Channel Library No.0-64)
End Of Exclusive
5.13.2.15. Program Change Table Bulk Dump
Format
System Exclusive Message
STATUS 11110000 F0
Manufacturer's ID No.(YAMAHA)
ID No. 01000011 43
n=0-15(MIDI Channel No.1-16)
SUB STATUS 0000nnnn 0n
Universal Bulk Dump
FORMAT No. 01111110 7E
138(128+10)bytes
BYTE COUNT 00000001 01
(HIGH)
BYTE COUNT 00001010 0A
(LOW)
'L'
01001100 4C
'M'
01001101 4D
' '
00100000 20
' '
00100000 20
'8'
00111000 38
'C'
01000011 43
'7'
00110111 37
'5'
00110101 35
'P'
DATA NAME 01010000 50
' '
00100000 20
Program Change Table(128bytes)
DATA 0ddddddd ds
: :
0ddddddd de
ee=(INVERT('L'+'M'+...+ds+...+de)+1) AND
CHECK SUM 0eeeeeee ee
7Fh
End Of Exclusive
EOX 11110111 F7
All data is divided into 7 bit units.
5.13.2.16. Program Change Table Bulk Dump
Request Format
System Exclusive Message
STATUS 11110000 F0
Manufacturer's ID (YAMAHA)
ID No. 01000011 43
n=0-15(MIDI Channel No.1-16)
SUB STATUS 0010nnnn 2n
Universal Bulk Dump
FORMAT No. 01111110 7E
'L'
01001100 4C
'M'
01001101 4D
' '
00100000 20
' '
00100000 20
'8'
00111000 38
'C'
01000011 43
'7'
00110111 37
'5'
00110101 35
'P'
DATA NAME 01010000 50
' '
00100000 20
End Of Exclusive
EOX 11110111 F7
