I I n n t t r r o o d d u u c c t t i i o o n n
This manual assists you with the operation or maintenance of your Stryker product. Read this manual before operating or
maintaining this product. Set methods and procedures to educate and train your staff on the safe operation or maintenance
of this product.
C C A A U U T T I I O O N N
• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this
manual.
• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation
resulting in injury to patient or operator. Modifying the product also voids its warranty.
N N o o t t e e
• This manual is a permanent part of the product and should remain with the product even if the product is sold.
• Stryker continually seeks advancements in product design and quality. This manual contains the most current product
information available at the time of printing. There may be minor discrepancies between your product and this manual. If
you have any questions, contact Stryker Customer Service or Technical Support at 1-800-327-0770.
P P r r o o d d u u c c t t d d e e s s c c r r i i p p t t i i o o n n
The Stryker P P r r o o C C u u i i t t y y ™ bed series is a powered, adjustable hospital bed used in combination with a patient support
surface.
The product contains siderails that you can lock into three positions, a headboard, and a footboard. The product has
Fowler, Gatch, and lift articulation capabilities, which aid to adjust surface contour, angle, and bed height. The product
transports patients aided by the optional Z Z o o o o m m ® function. The product features manual and electronic brakes. Product
height range is adjustable between 11.5 inches to 30 inches (29.2 cm to 76.2 cm), and 14 inches to 32 inches (35.6 cm to
81.3 cm) for a product with the optional Z Z o o o o m m function. The Fowler raises from 0 to 65 degrees (± 5 degrees).
The product is designed with various features, including Bed Exit, auxiliary AC outlet, bed extender, an IV pole, and the
following:
•
Integrated scale to track patient weight fluctuation throughout a patient's stay.
•
i i B B e e d d ® W W a a t t c c h h ™ to set various bed parameters to track bed position. i i B B e e d d W W a a t t c c h h provides visual alerts, while Bed Exit
provides both visual and audible alerts.
•
i i B B e e d d W W i i r r e e l l e e s s s s ™ option to monitor product parameters that a healthcare provider (HCP) views or sets at the bedside or
from a remote location.
•
Motion and feature lockouts, set by the HCP, to limit patient accessible controls for compliance to set bed parameters.
•
Nurse call capability through a wired connection or cable-free headwall with optional S S e e c c u u r r e e ® C C o o n n n n e e c c t t ™.
•
Integrates with the optional 2973 I I s s o o l l i i b b r r i i u u m m ® PE support surface to provide pressure redistribution, lateral rotation, turn
assist, low air loss, and max inflate functions.
•
Patient device holder with optional USB charger.
I I n n d d i i c c a a t t i i o o n n s s f f o o r r u u s s e e
The P P r r o o C C u u i i t t y y bed series is intended for use to assist with positioning, therapy, recovery, support, and transport of patients
within a healthcare delivery organization (HDO). The intended user is both HCPs (nurses, nurse aides, and medical
doctors) and human patients.
This product can be used with human patients that weigh more than 60 lb (27.2 kg), with a maximum height of 84 inches
(213.4 cm) without the bed extender or 96 inches (243.84 cm) with the bed extender.
The scale output is not intended to be used to determine diagnosis or treatment.
i i B B e e d d W W i i r r e e l l e e s s s s with i i B B e e d d W W a a t t c c h h provides clinical staff the ability to monitor specific bed parameters from a remote location
within a healthcare facility through unilateral data communication. The bed parameters include bed brake status, siderail
EN
6
3009-009-005 Rev AD.2
