Teile
Juli 2020
Beschreibung
Feedback Array Kit (cont'd)
Rotary
[Kit contains magnet assembly, pointer assembly, travel
indicator scale and M3 machine pan head screws qty. 2].
Stainless steel kits only for use with stainless steel mounting kits.
Aluminum
Stainless steel
Rotary Array Kit with Coupler
[Kit contains magnet assembly and NAMUR coupler]
Aluminum
Stainless steel
Elastomer Kit - includes all accessible elastomers
for one complete DVC2000 unit
Small Hardware Kit -includes all fasteners and plugs
(except mounting hardware) for one
complete DVC2000 unit
High Temperature Gasket Set
Includes O-ring seal (qty 1) and insulation
gaskets (qty 2)
Replacement housing
Plastic Vent Construction
Housing A (for GX Actuator)
G 1/4 & M20 Metric threaded ports
1/4 NPT & 1/2 NPT Imperial threaded ports
Housing B (for nonGX Rotary and Sliding-Stem)
G 1/4 & M20 Metric threaded ports
1/4 NPT & 1/2 NPT Imperial threaded ports
Metal Vent Construction
Housing A (for GX Actuator)
G 1/4 & M20 Metric threaded ports
1/4 NPT & 1/2 NPT Imperial threaded ports
Housing B (for nonGX Rotary and Sliding-Stem)
G 1/4 & M20 Metric threaded ports
1/4 NPT & 1/2 NPT Imperial threaded ports
Metal Vent Assembly
50
Teilenummer
Stückliste (siehe Abbildungen
5‐1, 5‐2 und 5‐3)
Hinweis
GG10562X012
Die in der Teileliste enthaltenen Teile sind nicht als Einzelkomponenten
GG10562X022
verfügbar. Alle Teile sind in den Ersatzteilsätzen enthalten.
GE71982X012
GE71982X022
I/P-Wandlerbaugruppe
GE08917X012
25
26
41
231
GE08918X012
Relaisbaugruppe
GE26550X012
2
45
Montagerahmenbaugruppe
GE24013X012
GE24011X012
3
16
GE24012X012
19
GE24010X012
45
51
GE74138X012
GE74137X012
Baugruppe der EMI-Abschirmung
GE74140X012
GE74139X012
11
29
GE20435X012
37
1. Alle Teile, die im I/P-Wandlersatz enthalten sind
2. Alle Teile, die in den Niederdruck- oder Hochdruck-Relaissätzen enthalten sind
3. Alle im Montagerahmensatz enthaltenen Teile
4. Alle im EMI-Abschirmungssatz enthaltenen Teile
Fasteners
O-Ring
I/P Converter
Screen O-Ring
(2)
Relay
O-Rings
Mounting Frame
Pressure Sensor Seal
Fasteners
O-Ring
O-Ring
Fasteners (3 req'd)
Conductive Gasket (Shield)
Primary Shield
Betriebsanleitung
D103176X0DE
(1)
(3)
(4)
