TCS Compact
1
2
1
Cleaning unit
Fig. 2
Technical data - version with long assembly stand
Ambient temperature
Relative humidity
Tab. 1
Ambient conditions during operation
Storage in a closed environment, ambient temperature
Ambient temperature for transport
Relative humidity
Tab. 2
Ambient conditions for transport and storage
Weight
Dimensions
Tab. 3
Weight, dimensions
BAL.0617.0 • 2021-05-20
369
270
200
250
2
Collecting tray
Version with long assembly stand
Approx. 29 kg
Approx. 250 mm x 369 mm x 1057 mm
3 Product description
145
2
3
168
4
3
Bottle holder for anti-spatter fluid
4 Support with base plate
+5°C to 50°C
Up to 90% at 20°C
+5°C to 50°C
-10°C to +55°C
Up to 90% at 20°C
Version with short assembly stand
Approx. 21 kg
Approx. 230 mm x 369 mm x 532 mm
EN - 9
