TCS Compact
Female connector type:
Amphenol 12-pole (14–12 p)
Operating
1/A PE
voltage
2/B 0 V
3/C 24 VDC/200 mA
Input
4/D 0 V/2.8 W
Loosen the clamping cylinder /
Close wire cutter (Y3)
5/E 0 V/2.8 W Lift up (Y1)
6/F 0 V/2.8 W Motor Rotation (Y2)
Output
7/G 0 V/max.100 mA
Lift cylinder is down(S1)
8/H 0 V/max.100 mA
Clamping cylinder is open (S2)
Fig. 26
Circuit diagram of transistor output: Proximity switch (NPN/sinking)
BAL.0617.0 • 2021-05-20
-X1.14
BK
8
-X1.13
BK
7
-X1.12
WH
6
-X1.11
WH
5
Loosen the clamping cylinder/
Close wire cutter (Y3)
WH
4
-X1.10
-X1.9
BU
-X1.8
BU
2
-X1.7
BN
-X1.6
BN
-X1.5
BN
-X1.4
3
BN
Female connector
1
-X1.3 PE
-X1.2 PE
-X1.1 PE
Clamping cylinder is open (S2)
Lift cylinder is down (S1)
Motor rotation (Y2)
BN
Lift up (Y1)
WH
BN
WH
BN
WH
13 Appendix
A1
A2
A1
A2
A1
A2
EN - 37
