2.6. LED Indicators:

2.6.1. EOC 30-01 | EOC 30-21
Label
ON
Power Powered by DC12V
Green = LAN1 port is active
LAN1
Orange = LAN1 = 1 Gbps.
Green = LAN1 port is active
LAN2
Orange = LAN1 = 1 Gbps.
Link/Act EoC+RF port is active
EOC master is diagnosing EOC connection
Diagnosis
toward/from endpoint
Not
Forcing to default settings via reset button.
labelled
2022-01-17 | Technical improvements, changes in design, printing and other errors reserved. | AXING-BA_EOC-30-xx.pdf
Status
Flashing
N/A
Data traffic active
Data traffic active
Data traffic active
Bootloader mode
