7
U30 / U50 ASSEMBLY COMPLETE!
98
MXR20_AG_Bikes_r1_0_B.indd 98-99 MXR20_AG_Bikes_r1_0_B.indd 98-99
SEAT ADJUSTMENT
To determine proper seat position, sit on the seat and position the ball
of your foot on the center of the pedal. Your knee should bend slightly
at the furthest pedal position. You should be able to pedal without
locking your knees or shifting your weight from side to side.
NOTE: It is recommended that you do not sit on the seat while adjusting its position.
U30 U50
To adjust, loosen the adjustment To adjust, lift up on the adjustment
knob by turning it two half turns lever and hold while sliding the post
counterclockwise. Pull out the up or down to the desired setting.
knob to unlock the post, and Release the lever to lock in place.
adjust the post up or down to Please check to be sure seat post is
the desired setting. Release the locked in place before each use.
knob to lock in place. Turn the
knob clockwise until tightened.
Please check to be sure seat post is
locked in place before each use.
HANDLEBAR POSITION
To adjust, rotate the adjustment
lever down and slide the handlebar
set to a position that puts the
handlebars within comfortable reach.
Lock the mechanism by lifting up
on the adjustment lever until tight.
