Adjust the Side Guides and Envelope Separation

Adjust the side guides and envelope separation as follows.
1. Rotate thumb wheel D to move the side guides C apart.
2. Put a small stack of envelopes between the side guides.
3. Move the side guides towards the envelopes. The space between the side guides and
the envelopes should be such that the envelopes have just enough play to move freely.
4. Pull down small lever B to set the separation.
5. Insert one envelope up to the stoppers. The position of the envelope is flap down and
trailing (bottom side of the envelope pointing to the system).
6. Return lever B.
If the distance between the side guides is too large, the envelopes
will twist sidewards, when transported into the machine.
