Specifications; Technical Specifications - FP FPi 6600-2 Betriebsanleitung

11

Specifications

Technical Specifications

Model
Type
Theoretical max. speed
Power consumption
Voltage tolerance
Fuse
11
Approvals
Noise Level
Operating temperature
Humidity
142
DS-90i, FD6606, M8800i, FPi6600-2
Folder and inserter system for medium of-
fice use.
4300 inserts per hour, depending on applic-
ation.
100V AC/50Hz/4.0 Amps.
115V AC/50/60Hz/4.0 Amps.
230V AC/50Hz/2 Amps.
100V: +6% / -10%
115V: +6% / -10%
230V: +10% / -10%
100/115 Vac: T 5.0 A, 125 V .
Time lag, 5.0 Amps. rated current, 125 V.
230 Vac: T 3.15 A H, 250 V.
Time lag, 3.15 Amps. rated current, high
breaking capacity, 250 V.
EMC Certificate conform EMC-Directive.
FCC Certificate conform 47CFR, part 15
CB Certificate conform IEC 60950-1
UL Listed I.T.E. (Information Technology
Equipment)
Conform UL-IEC 60950-1, file E153801
Conform NEN-EN-IEC 60950-1 and derivat-
ives.
<70 dBA (according to ISO 11202)
10°C - 40°C (50°F-104°F)
30%-80%
