Remarks:
• The specification of the paper handling equipment is often wider than that of the
envelopes and documents handled. The condition of material handled will limit the
specified environmental conditions.
• We recommend that materials to be handled are stored at a temperature of 20°C
(68°F) with a relative humidity factor of 50%. If difference in temperature occurs
between store room and mailing area, the material has to be stored near the machine
at least 24 hours before use.
• Self-copying paper may cause rubber parts to wear quicker. The rubber used in this
machine has the best resistance to Wiggins Teape material.

maxiFeeder Specifications

Model
Type
Theoretical max. speed
Power consumption
Approvals
Height
Width
Length
Weight
Noise level
Operating temperature
Humidity
Feed tray capacity
Model MF-4
High capacity feeder
see Technical Specifications
Low voltage supplied by the inserter sys-
tem.
EMC Certificate conform EMC-Directive.
FCC Certificate conform 47CFR, part 15.
UL Listed I.T.E. (Information Technology
Equipment),
conform UL-IEC 60950-1, file: E153801.
Conform NEN-EN-IEC 60950-1 and derivat-
ives.
210 mm (8.3 inch)
285 mm (11.2 inch)
425 mm (16.7 inch)
5.05 kg (11.1 lbs)
see Technical Specifications
10°C - 40°C (50°F-104°F)
30%-80%
1200 sheets A4 80 gr.
320x Business Reply Envelopes
