Specifications; Technical Specifications - FP FPi 4700 Betriebsanleitung

10

Specifications

Technical Specifications

Model
Type
Theoretical max. speed
Power consumption
Voltage tolerance
10
Fuse
Approvals
Noise Level
114
DS-75i, FPi4700, FD6304i
Folder and inserter system for medium of-
fice use.
3800 inserts per hour, depending on applic-
ation.
Off mode: 0 W
Standby: 0.33 W
Idle: 15.5 W
Run mode: 160 W
100V: +6% / -10%
115V: +6% / -10%
230V: +10% / -10%
100/115 Vac: T 5.0 A, 125 V.
Time lag, 5.0 Amps. rated current, 125 V.
230 Vac: T 2,5 A H, 250 V.
Time lag, 2.5 Amps. rated current, high
breaking capacity, 250 V.
EMC Certificate conform EMC-Directive.
FCC Certificate conform 47CFR, part 15
CB Certificate conform IEC 60950-1
UL Listed I.T.E. (Information Technology
Equipment)
Conform UL-IEC 60950-1, file E153801
Conform NEN-EN-IEC 60950-1 and derivat-
ives.
<66 dBA (according to ISO 11202)
<67 dBA With High Capacity Vertical
Stacker
