Operating instructions -- PowerMax cam unit PMU
4. Now push the cam slide in the front
position (step 1). You can remove
the slide stop (step 2).
5. N ow screw the Lock-Out-System
SN5651- PMU-LOS-*** at the position
of the slide stop.
6. Turn the screws SN5651-LOS-SPS-***
in the slide stop.
Tighten the screws cautiously to fasten
the cam slide.
