PowerMax cam unit SN5650-PMU-0330 — SN5650-PMU-1200

3.1 Description of the construction types

Unique in the world is the differentiation of a cam program in 3 types:
BASIS, MEDIUM, PREMIUM.
These types which are totally similar in the dimensions differ exclusively in their performance values and
the equipment details.
The BASIS cam is equipped with guide elements out of bronze-graphite. The working surface is out of
cast iron.
The MEDIUM cam is equipped with guide elements out of sintermetal, the working surface is out of cast
iron and the active return can be adjusted.
The PREMIUM cam is equipped with guide elements out of sintermetal, the working surface is a remov-
able mounting plate and the active return can be adjusted.
Attention:
The mounted gas springs serve for the additional reset of the cam slide.
The working powers which are necessary for the operation are absorbed by the
active return (only Medium- and Premium version).

4. Scope of delivery

The PowerMax cam units are delivered preassembled and with a precise guide clearance.
The mounted gas springs, unless otherwise desired, are delivered with maximal filling pressure.
The working surface can already contain client-specific insertions. Also Premium special mounting
plates belong to these.
All cams can also be produced for the machining of high strength sheets, contrary to the angles in five
steps described in the catalogue, in all intermediate angles according to customers' requirements.
Please contact us.
