PowerMax cam unit SN5650-PMU-0330 — SN5650-PMU-1200

3. Characteristics

The execution of this STRACK cam unit is a "side cam unit type SN5650".
These cams can be mounted: - without mounting plate as "Basis" and "Medium" version
These PowerMax cam units consists of:
with the corresponding accessories
All PowerMax cam units are equipped with gas springs.
In this system, nitrogen with a purity grade of ≥99,8 vol.-% is used as active fluid medium for the
gas springs.
The cylinder dimension, cylinder number and filling pressure (different at the diverse cam types)
determine the reset force which is available.
Please consider that all PowerMax cam units are the successful result of a long development work.
The resulting advantages optimally develop at the full exploitation of the respective cam stroke
during the work process; that means, the stamping- and benching operation of the cam unit should
be carried out in the front end position.
The complete exploitation of the cam stroke allows the maximal intervention of the active return and
the therewith connected highest possible supply of retracting- and stripper forces (about 10 % of the
pressing force).
In the front endpoint of the cam stroke there is the maximal retraction of the gas spring. Generally
applies: The construction and the resulting values, like assembly height and restoring forces, require
that the cam unit is mounted in the front end position.
6
STRACK NORMA GmbH & Co. KG · Königsberger Str. 11 · D-58511 Lüdenscheid · Tel +49 2351 8701-0 · www.strack.de
- with mounting plate as "Premium version"
- cam retainer
- cam body
- driver
PowerMax
I
Operating instructions -- PowerMax cam unit PMU
