Strack PowerMax SN5650-PMU-0330 Bedienungsanleitung Seite 23

PowerMax Schiebereinheit SN5650-PMU-0330 — SN5650-PMU-1200
Type
PMU 0460
SN5654-PMU-LOS-0460-00 00°
SN5654-PMU-LOS-0460-05 05°
SN5654-PMU-LOS-0460-10 10°
SN5654-PMU-LOS-0460-15 15°
SN5654-PMU-LOS-0460-20 20°
SN5654-PMU-LOS-0460-25 25°
PMU 0580
SN5654-PMU-LOS-0580-00 00°
SN5654-PMU-LOS-0580-05 05°
SN5654-PMU-LOS-0580-10 10°
SN5654-PMU-LOS-0580-15 15°
SN5654-PMU-LOS-0580-20 20°
SN5654-PMU-LOS-0580-25 25°
PMU 0700
SN5654-PMU-LOS-0700-00 00°
SN5654-PMU-LOS-0700-05 05°
SN5654-PMU-LOS-0700-10 10°
SN5654-PMU-LOS-0700-15 15°
SN5654-PMU-LOS-0700-20 20°
SN5654-PMU-LOS-0700-25 25°
PMU 0850
SN5654-PMU-LOS-0850-00 00°
SN5654-PMU-LOS-0850-05 05°
SN5654-PMU-LOS-0850-10 10°
SN5654-PMU-LOS-0850-15 15°
SN5654-PMU-LOS-0850-20 20°
SN5654-PMU-LOS-0850-25 25°
PMU 1200
SN5654-PMU-LOS-1000-00 00°
SN5654-PMU-LOS-1000-05 05°
SN5654-PMU-LOS-1000-10 10°
SN5654-PMU-LOS-1000-15 15°
SN5654-PMU-LOS-1000-20 20°
SN5654-PMU-LOS-1000-25 25°
