Now take the Top Tether (TT) and put it under the
head rest along to the appropriate Top Tether anchor
point of the car. This can be found in the instruction
manual of the car.
Look out for this symbol in your vehicle:
Click the Top Tether into place and pull the belt
tightly. Please check again, if the child car seat is
fi xed safely on the seat.
Attention:
If the Top Tether (TT) has been correctly fi xed, a green marking appears on
the safety button.
Precaution!
Make sure you do not accidentally use the luggage hooks instead of the Top
Tether anchoring point.
Only if the HEYNER® Capsula MultiFix ERGO 3D/
HEYNER® Capsula MultiFix AERO with the ISOFIX anchors (IA)
is properly installed in the car the seat can protect your child optimally.
23
1.4. The child in the HEYNER® Capsula MultiFix ERGO 3D /
HEYNER® Capsula MultiFix AERO

1.4.1 Securing the child

• Loosen the shoulder belts by pressing the belt adjuster (GM) and pull
the harness belts (G2) toward you.
Attention: Do not pull on the shoulder pads.
Open the seat belt buckle (D) and the belt system (G).
Open the buckle (D) and the harness (G), put the harness belts (G2) to
the left and right of the pages.
A
Now put the child in the seat of the HEYNER® child car seat so that
B
the bottom is deep in the seat. Put the two buckle tongues (C) of the
harness belt (G2) together and connect them with the buckle (D) until a
C
clear << click >> is audible.
By pulling on the central adjusting belt (G5) make sure that the
harness belts touch the child fi rmly and are not twisted.
English
GB
Press
click
