English
Only a proper fi xing of BOTH ISOFIX connectors (IK) ensures that the seat
is secured properly and off ers full protection to your child in the car!!!
The supporting device (S) can be adjusted in 18 positions. Press the pedal
release button (SF) and pull the pedestal to the fl oor. If the pedestal
stands securely on the fl oor, the stand display will be completely green.
If the indicator is red, repeat the procedure.
WARNING: The supporting device must not be suspended in the air or be
covered with any objects. Always make sure that the stand indicator is green.
Please check once more, if the child car seat is securely fi xed onto the seat.
Only if the HEYNER® MultiFix TWIST 2.0 with the
ISOFIX anchors (IA) and the supporting device (S) are properly installed in
the car the children's car seat can achieve optimal safety for your child.

4.3. Height adjustment of the headrest (A) and the harness straps (SG)

to the size of your child.

To adjust the height of the headrest (A) to the size of your child touch the
back of the headrest and pull the adjusting lever (H) up. Now you can,
depending on the size of your child, adjust the headrest (A) to it's desired
height.
As soon you have reached the correct height, release the adjusting lever
(H) and the headrest (A) snaps into the desired height. Only a well
adjusted headrest ensures maximum safety. The headrest should be adjusted so that the integ-
rated 5-point harness system (G) runs at shoulder height of the child.
The headrest can be adjusted in 7 diff erent positions.
The harness system is adjusted with the height of
the headrest.
The shoulder straps are fi rmly attached to the
headrest and do not need
to be adjusted separately.
Adjust the size of the harness system (G) to your
child by adjusting the headrest (A).
29
L+R
CHECK
press CHECK
The headrest must be adjusted so that the distance between the shoulders
of the child and the headrest does not exceed 3 cm (about 2 fi nger widths).

4.4. Fastening your child's seatbelt

Make sure that the headrest is locked in place before seating your child.
Loosen the shoulder straps by pressing the belt adjuster (GV) and pull the
harness straps (G2) towards you.
Attention: Do not pull on the shoulder pads.
Open the seat belt buckle (D) and the belt system (G).
Place the harness straps (G2) to the left and to the right side. Now place the
child into the seat of the HEYNER® MultiFix TWIST 2.0 so that the buttocks
press deeply into seat.
Insert the two buckle tongues (C) of the harness strap (G2)
and connect it to the belt buckle (D) until you hear a clear „click" sound.
By pulling on the central adjusting belt (G5) make
sure that the harness belts touch the child fi rmly and are not twisted.
Avoid thick clothing under the belt especially in the winter.
WARNING: Make sure that the belt buckle is free from any dirt. Only clean
belt locks engage audibly and safely.
IMPORTANT:
Make sure that the straps are neither twisted nor jammed. Also check the
lap belts. These must not be twisted and should be as low as possible
above the child's hip.
WARNING: There should be no more than a fi nger's width between the
body and straps.

4.5. Sitting and reclining positions of the child

This children ´ s car seat is equipped with a reclining position. The operation
is quick and easy with just one hand. By pressing the positioning handle
(PG), you are able to bring the seat in the desired position for your child.
English
Press
Pull
30
