The installation must only be carried out by an adult!
Therefore, ensure the correct installation in the car and read the instruction
manual. The installation must be performed only by adults!
1.2. Adjusting to the size of the child
1.2.1. Preparation
The HEYNER ® Capsula MultiFix ERGO 3D carry a head cushion (A1) and
a reduction cushion (A2) (the HEYNER ® Capsula MultiFix AERO are
equipped with only one head cushion).
The cushions are provided for the special protection of young children
weighing 9kg - 18kg. We recommend removing this only when the child
is too big for it,at least if the child weighs 18 kg
19
1.2.2 Height adjustment of headrest (A) and
shoulder belts (G2) to the size of your child.
The HEYNER® Capsula child car seats have their
own 5-point safety harness (G). Adjust the size of
the harness system to your child by adjusting the
headrest (A).
To do this, put the HEYNER ® child car seat on a
normal chair and place the child into it. To ensure optimum belt run,
the shoulder pad belts (SG), depending on the size of the child, have
to run directly in the middle of the shoulders, not too high and not too
deep.
To adjust the height of the headrest (A) to the size of your child touch
the back of the headrest and pull the lever (H) up. Now you can,
depending on the size of your child, adjust the headrest (A) to the
desired height. Once you have reached the right height, release the
lever (H) and the headrest (A) locks into the desired height.
