Lay down the booster (fig.2) on the floor and the backrest (fig.1) flat right behind. Then thread the
connecting hooks (A) on the bottom of the backrest into the fitting holes (B) on the back of the
booster with a firm downwards motion. Now bring the backrest slowly upright, 90°to the booster.
The connecting hooks should now slip into the fitting holes with an audible sound. As the result the
backrest should be well fixed to the booster in the upright position. It must not slip away now.
Otherwise you may not have fixed it very well an using it would be dangerous. In this case please
repeat the first steps of this part of the instruction.

2.2. Conditions for installing the seat in the car

®
The HEYNER HEYNER
MaxiProtect AERO may be placed on all passenger seats (fig.3) of the vehicle that
are equipped with a three-point-vehicle-belt. The child seat must not be positioned on a vehicle seat,
which only has a lap belt (O), example given the centre back seat of cars with three seats in the
back.
The three-point-belt of a vehicle (fig.6) is made of 4 parts: the lap belt (O), the diagonal belt (N), the
belt latch (P) and the belt buckle (Q).
®
2.3. Installing the HEYNER HEYNER
MaxiProtect AERO into your car (fig.4)
®
Now place the HEYNER HEYNER
MaxiProtect AERO onto the passenger seat in the car and set your child
into it.
Secure your child in it by fastening the lap and diagonal belts of the three-point-vehicle-belts and
locking it with an audible »click« sound. The lap belt (O) needs to lead under the fixation lugs (C) on
both sides. The diagonal belt (N) needs to lead under the fixation lugs (C) only on the belt buckle's
(Q) side. (Fig.4)
Thread the diagonal belt through the side belt guide (E)(fig.5) on bottom of the headrest and tighten
it in the direction of the retracting mechanism.
9
Make sure that the diagonal belt lies firmly against the child's body and is not twisted.
All belts must lie tightly against the child's body without being twisted. The lap belt must lie flat
over the child's thigh. If necessary, use the vehicle's belt height adjuster to correspond to your
child's height. Please check the belt-run at least every six months and adjust the backrest to the
new size of your growing child. Make sure that the lap belt runs through the fixation lugs
(C)(fig.2) on both sides of the booster seat and that the diagonal belt goes only to the side
leading to the belt buckle.
Attention: Never fasten the lap seatbelt differently, otherwise the child will not be held properly.
2.4. Adjusting of the headrest to the child's size (fig.5)
In order to adjust the height of the head rest to your child's size push the seat down on the
vehicles seat to keep it there. With the other hand de-block the head rest de-block lever (Z) on
the back of the head rest by pulling it backwards at the same time. Keep the lever de-blocked
and pull the head rest simultaneously up or down, according to the child's size. Relase the lever.
The head rest needs to be fixed in one of the guide wholes with an audible sound. Please check
by pulling on the head rest, if it does not move anymore without pulling the lever. The middle of
the head rest needs to be exactly at the height of the middle of the child's head to have the
highest side protection effect. The distance between head rest and shoulder of the child should
be 2 fingers. The headrest is adjustable in 7 different positions.
Attention: Check regularly if the headrest is still appropriate to your child's size.
Warning: Do not fasten the belts in any other way than described here, otherwise the child will
not be held or secured properly. Make sure that the diagonal belt is carefully positioned and
does not run too close to the child's neck. All belts must lie firmly against the child's body without
twisting. If necessary, install a belt height adjuster mechanism into the car to correspond to your
child's size.
