sematic DRIVE SYSTEM Bedienungsanleitung Seite 38

If the option DISPLAY CONTRAST is chosen, the display shows a dark square and allows
the setting of the LCD contrast, by means of the
firm with "OK" key. The following options are available:
• "BACK": Press key F1 to restore the menu MAINTENANCE
• "MENU": Press key F3 to restore the Main Menu
If the option BATTERY is chosen, the display shows either battery voltage (in Volt) and sta-
tus (in charge or in use) or just "NOT PRESENT"
The following options are available:
• "BACK": Press key F1 to restore the menu MAINTENANCE
• "MENU": Press key F3 to restore the MAIN MENU
If the option MAIN LIFT CONTROLLER MONITOR is chosen, the system IS BACK TO FOL-
LOW MAIN LIFT CONTROLLER'S SIGNALS; the display shows a complete list of the
input/output signals with their value.
When the input or output signal is activated the character on the display will chan-
ge their graphic in white with dark background.
The following options are available:
• "BACK": Press key F1 to restore the menu MAINTENANCE
• "MENU": Press key F3 to restore the MAIN MENU
If the option WARRANTLY is chosen, the display shows:
• warrantly expiration date
• the activity hours left before warrantly expiration
• the software version in use
• the motor code in use
The following options are available:
• "BACK": Press key F1 to restore the menu MAINTENANCE
• "MENU": Press key F3 to restore the MAIN MENU
