6.4.2 Main Lift Controller Test (when moving + parking)
If the main lift controller test is set to MOVING+PARKING, the Door Controller
checks for the Ka or Kc signals coming from the main lift controller both during
movement (Ka signal during the opening cycle, Kc signal during the closing cycle)
and during parking (Ka signal while opening, Kc signal while closing).
This test setting should only be applied for main lift controllers that are equipped
with just 1 relay to command both opening and closing.
The Door Controller detects signal drops exceeding 200ms; this is interpreted as NO
MAIN LIFT CONTROLLER INPUT alarm if the relevant parameter MAIN LIFT CON-
TROLLER TEST is set on "MOVING+PARKING".
In case of signal failure, the Door Controller acts as described in the parameter set-
ting NO MAIN LIFT CONTROLLER SIGNAL (see § 6.4.3).
6.4.3 No MLC Signal
This submenu is not available if the parameter MAIN LIFT CONTROLLER TEST is set
to "OFF".
If the MAIN LIFT CONTROLLER TEST is set either to "WHEN MOVING" or to
"WHEN MOVING+PARKING" this menu allows the selection of the Door
Controller behaviour that must be adopted in case of signal loss or failure of
the main lift controller.
The following 3 options are available:
6.4.3.1 Instant Stop
If the "INSTANT STOP" option is activated (default setting), the door control-
ler stops the door movement.
6.4.3.2 Low Speed to Stop
If the "LOW SPEED TO STOP" option is activated, the door controller switches
to low speed until completion of the interrupted movement.
6.4.3.3 Low Speed Cycle
With the parameter NO MLC SIGNAL is set on "LOW SPEED CYCLE":
• If the doors are opening or fully opened, the door controller operates the
buzzer output, it stays open for a time then close at low speed;
• if the doors are closing but not fully closed, the door controller operates the
buzzer output, reverses direction, opens fully and stays open for a time
then close at low speed;
• if the doors are closed, the doors will stay in the closed position, and the
buzzer is operated for a short time.
• The buzzer will be de-activate upon door closed.
6.4.4 Main Lift Controller Input Alarm
This option allows the installer to choose to consider or not consider a recor-
ded fault the case that the door controller detects the signal failure, both Ka
and Kc, when
6.5 Car Door Locking Device (USA = Restrictor)
This option must be set when the optional car door locking device is installed. This function
provides for proper operation with the car door locking device.
6.6 Full or framed Glazed Paneled Doors
In presence of car and landing door with Glazed Paneled Doors, this feature must be acti-
vated. When active, the OPENING HIGH SPEED as additional featurevalue is restricted to
conform to EN81-1/2 Standard, 7.2.3.6.d.
