sematic DRIVE SYSTEM Bedienungsanleitung Seite 25

Code on Viewed error
display
08 Over-voltage
09 PWM-Trip
10 Internal
Notes:
1 This alarm can only occur if the MAIN LIFT CONTROLLER TEST has been set either to
"WHEN MOVING" or "MOVING+PARKING" and the "MAIN LIFT CONTROLLER INPUT
ALARM" parameter has been set to "ON" (see § 6.4).
2 This alarm indicates an excessive strain in the operator's functioning; it is advisable to
check that the system has no friction whatsoever, especially during the opening phase.
3 This alarm can only occur if the REVERSING SYSTEM parameter has been set to "EXTER-
NAL" (see § 6.2).
4 If both connections (motor and Encoder signals) are inverted, the door opens when a
closing signal is received and closes with an opening signal. The Door Operator is pre-
wired and tested by the manufacturer; so special attention must be taken when repla-
cing motor and/or cables.
w w w . s e m a t i c . c o m
ALARMS TABLE
Error description
Over-voltage in the power supply
Impulse over-current
Generic alarm due to an internal mal-
function of the Door Controller
24
infosem@sematic.com
Action undertaken by
Door Controller
Door Controller switches
to low speed, signals
the error and performs
an auto reset; after 5
occurrences within 20
minutes the system
stops
Auto reset when normal
operating conditions are
restored; after 5 occur-
rences within 20 minu-
tes the system stops
Auto reset
when normal
operating con-
ditions are
restored
