On the display the following options are viewed:
•
Fast setting
•
Reversing system force
•
Advanced Settings
•
Set Factory Default
•
Manufacturer menu
•
Using keys
and
option
•
Using the "OK" key, confirm the option
•
The following options are available:
•
"BACK": press key F1 to restore the "Main Menu";
•
"MENU": press key F3 to restore the "Main Menu";
8.5.1 Option "Fast settings"
This option allows one to easily and quickly modify the speed profiles. Choose this
option as indicated in the first part of Paragraph 8.5
The following options are viewed on the display:
•
OPENING PARAMETERS;
•
A diagram shows the examined cycle speed profile (opening or closing);
•
On the upper left side a number is given which indicates the currently used speed
percentage. Using keys
•
On the lower left side a number is given which indicates the currently used speed
m/s.
•
On the lower left side a number is given which indicates the time "T:" in seconds
required to perform the opening cycle;
•
Using keys
or decreased;
•
Using keys
meters which are available are "HIGH SPEED", "LOW SPEED", "COMFORT";
•
The parameter "Comfort" determines acceleration value or deceleration value
that the controller has to comply while changing profile velocity. This parameter
is important to establish the panel fluidness movement. The display shows the
parameter value expressed in percentage and below the real value of the para-
meter;
•
At the end of the parameters modifications the diagram will adapt and will show
the new speed profile;
•
Press key F2 (<> - ><) to check the door operation with the new set profile and,
by performing an opening cycle, this will update the indicator of time necessary
to carry out the opening cycle with the new set profile;
•
Press key F3 (NEXT) to carry on the profile setting with the CLOSING
PARAMETERS setting; the same operations must be followed as above in relation
to the OPENING PARAMETERS setting;
•
Press key F1 (BACK) to the previous menu;
8.6. Option "Set Factory Default"
Choose this option to reset the movement parameter to the factory default values.
•
Connect the handset to RJ45 connector
•
If necessary, using keys
"OK" key or confirm the suggested language with "OK".
•
Using keys
and
•
Press the "OK" key to confirm the option.
•
On the display the following options are viewed:
•
FAST SETTING
•
REVERSING SYSTEM FORCE
•
ADVANCED SETTINGS
© SEMATIC
All rights reserved
Changes can be made without notice
see www.sematic.com for latest release
run through the menu "Profile setting" and choose the required
and
and
, the value of the speed parameter is respectively increased
and
, it is possible to change the parameter to be set; the para-
and
choose the required language and confirm with the
run through the MAIN MENU and choose PROFILE SETTING;
infosem@sematic.com
on the handset to modify it.
29
