sematic DRIVE SYSTEM Bedienungsanleitung Seite 14

INCOMING SIGNALS FROM THE DOOR CONTROLLER
Signal
Opening control Ka
(coming from the Main
Lift Controller)
Closing control Kc
(coming from the Main
Lift Controller)
Forced closing
control at
low speed Kb
Re-Opening control Kn
Fire-Fighting Contact
Kff
Contact K2TB
Encoder
Signals
Contact KEOD
Handset (Optional)
Auxiliary Contact Kaux
© SEMATIC All rights reserved
Changes can be made without notice
see www.sematic.com for latest release
Connector Contact Type &
Pins Normal State
Connector These connections require
pins 5 - 15 dry (voltage free) contacts
(contact open when inac-
tive)
Connector These connections require
pins 3 - 15 dry (voltage free) con-
tacts. (contact open when
inactive)
Connector These connections require
pins 15 - 22 dry (voltage free) contacts
(contact open when inac-
tive)
Connector These connections require
pins 15 - 23 dry (voltage free) con-
tacts. (both logics availa-
ble)
Connector These connections require
pins 15 - 39 dry (voltage free) con-
tacts. (contact open when
inactive)
Connector These connections require
pins 15 - 41 dry (voltage free) con-
tacts.
(contact open when inac-
tive)
Connector Factory prewired
RJ45 (A) connector
Connector These connections require
pins 15 - 40 dry (voltage free) con-
tacts. (contact open when
inactive)
RJ45 connec-
tor (B)
Connector These connections require
pins 15 - 42 dry (voltage free) con-
tacts. (contact open when
inactive)
infosem@sematic.com
When the Door Controller is
installed on a Front & Rear
entrance car, it is important
that the opening and closing
controls have no common con-
tacts between the two doors.
Shielded,
Highly Recommended
The main lift controller may
signal the forced closing when
the photocell (or similar device)
shall be made inoperative due
to a failure, or after several
door closing failures.
See sections 4.1.1 & 4.1.2. for
the connection to the door
controller
See section 6.9
This signal allows the door
controller to recognize diffe-
rent door opening widths in
the same lift installation.
Given this signal, the opening
and closing operations are car-
ried out referring to an alter-
native TB (door width recorded
by an additional self-learning
cycle).
This connection is to signal the
use of the Sematic E.O.D.
Emergency Opening Device to
the Door controller
Not yet implemented
13
w w w . s e m a t i c . c o m
Notes
Grounded Wire
