8.3 Self-learning cycle activation by means of the handset
By using the handset to operate a self-learning cycle, interferences with possible signals
coming from the main lift controller are avoided
• Power the system
• Turn "ON" the door controller; if there are any closing or opening signals from the main
lift controller, the operator will perform the relevant reset cycle in low speed up to the
end run limit.
• Connect the handset to RJ45 connector
• If necessary, using keys
"OK" key or confirm the suggested language with "OK"
• Using keys and
• Using the "OK" key confirm the option.
• If the operator is not on a closing position use key F2 (><) to allow the door to com-
plete a closing cycle in low speed
• Once the closure has been made, push again key F2 (<>) to allow a complete opening
cycle in low speed
During this operation please check carefully that the operator completes its total
expected travel. At the end of the opening cycle the self-learning cycle is completed.
This will be signalled with the information "Self-learning completed".
The following will be requested: "Guided Profile setting?"
• Press the "OK" key to choose the option "Fast settings"
• Press key F1 (EXIT) to restore the "main menu"
8.4 Reversing System Force setting by means of the handset
• Connect the handset to RJ45 connector
• If necessary, using keys
"OK" key or confirm the suggested language with "OK".
• Using keys and
• Press the "OK" key to confirm the option.
• On the display the following options are viewed:
• FAST SETTING
• REVERSING SYSTEM FORCE
• ADVANCED SETTINGS
• SET FACTORY DEFAULT
• MANUFACTURER MENU
• Using keys and
REVERSING SYSTEM FORCE
• Using the "OK" key, confirm the option
On the left display side are shown three values selectable with
maximum value (MAX), the setted value (SET) and the minimum value (MIN).
Is possible to change those values with
On the right display side is shown a graph with the setted force percentage regarding the
maximum force.
• Using keys and
• Press key F2 (<> - ><) to check the door operation with the set reversing force value
• Press key F3 (MENU) to restore the MAIN MENU
• Press key F1 (BACK) to restore the menu PROFILE SETTINGS;
8.5 Speed Profile and High Speed adjustments by means of the Handset
• Connect the handset to RJ45 connector
• If necessary, using keys
"OK" key or confirm the suggested language with "OK".
• Using keys and
• Press the "OK" key to confirm the option
