• The following options are available:
• "BACK": press key F1 to restore the MAIN MENU
• "MENU": press key F3 to restore the MAIN MENU
8.8.1 Option "Opening Parameters"
The following options are viewed on the display:
• LOW START SPEED
• ACCELERATION START
• ACCELERATION
• HIGH SPEED
• OFFSET DECELERATION
• DECELERATION
• LOW SPEED
• FITTINGS
For each of the above listed parameter the parameter name is displayed at the top,
the current value is displayed at the bottom with the relevant unit measure; the
up/down arrow keys allow changing the current value.
• The following options are available:
• "BACK": press key F1 to restore the MAIN MENU
• F2 KEY: to open and close the door, to test the modified profile
• "DRAW": press key F3 to update the speed profile drawing
8.8.2 Option "Closing Parameters"
The following options are viewed on the display:
• LOW START SPEED
• DECELERATION STOP
• ACCELERATION
• HIGH SPEED
• OFFSET DECELERATION
• DECELERATION
• LOW SPEED
• FITTINGS
For each of the above listed parameter the parameter name is displayed at the top,
the current value is displayed at the bottom with the relevant unit measure; the
up/down arrow keys allow changing the current value.
• The following options are available:
• "BACK": press key F1 to restore the MAIN MENU
• F2 KEY: to open and close the door, to test the modified profile
• "DRAW": press key F3 to update the speed profile drawing
8.8.3 Option "Change Password"
This option allows the user to change to access password to his /her will; input the
new password as follows:
Select the desired code digit using keys
different digits. Press OK at the end.
© SEMATIC All rights reserved
Changes can be made without notice
see www.sematic.com for latest release
infosem@sematic.com
and ; Use keys
31
w w w . s e m a t i c . c o m
and to moves to
