Loading the System

Document Orientation

The touch screen shows how to load documents and envelopes into the feeders. The table
shows the meaning of the symbols:

Document Feed Trays

Install the Document Feed Trays
Place the document feeder trays in position:
1. Hold the document feeder tray slightly inclined as shown in the figure.
2. Place the front end of the document feeder tray underneath the two black rollers.
Address carrier face up and leading (top
address)
Address carrier face down and trailing (top
address)
Enclosure face up
Enclosure face down
