Automatic Measurements

The following automatic measurements can be accessed by pressing the Mea-
sure button. Up to four measurement menus with 22 measurement options can
be selected by turning rotary switch. You can activate the individual softkey and
press the rotary switch to set the measurement type.
Table 7 List of automatic measurement options
Time
Measurements
• +Duty
• –Duty
• Frequency
• Period
• Rise Time
• Fall Time
• +Width
• –Width

Data Logger

The data logger acts as a recorder to log and plot input signal trend. This
function is applicable to voltmeter, ohmmeter and auxiliary meter
measurements. Refer to Table 3 for measurement functions of each meter.

Quick Help

The U1600A Series includes built- in Quick Help support. To view the quick
help for each function or subfunction, press the Help button. You can turn the
rotary switch clockwise to go to the next page. Press the Help button again to
exit the Quick Help. Quick Help in other languages are available in the accom-
panying product reference CD and need to be installed prior to usage. To view
the installed Quick Help language, enter Utility mode in the User menu and
press F2 on page 1/4 for language selection.
Refer to U1602A and U1604A User's and Service Guide for more detailed information of the
product. All product documentation and software are included in the product reference
CD-ROM.
Voltage
Measurements
• Mean
• Cycle Mean
• Amplitude
• Base
• Maximum
• Minimum
• Peak- to- Peak
• RMS
• Top
Phase and Delay
• Phase
• Delay
14
Preshoot and
Overshoot
• Preshoot
• +Overshoot
• –Overshoot
