Setting Up the SmartMonitor 2 for Respiration and Heart Monitoring

After you unpack your SmartMonitor 2 and make sure you have all the parts, follow the
steps listed below to set it up:

Step 1: Set the SmartMonitor 2 on a Clean, Flat Surface.

•
Be sure the speaker is not blocked.
•
To avoid interference, be sure that no other electrical appliances are within three
feet of the unit.
•
Make sure the monitor is close enough to connect to the baby comfortably.

Step 2: Connect the Patient Cable to the SmartMonitor 2.

•
Insert the round end of the patient cable into the bottom round connector found on
the front of the SmartMonitor 2.
•
Line up the notch on the connector and push until you feel the connector snap into
place.
•
To remove the patient cable, grasp the patient cable at the base of the patient
input connector and gentle pull back. Do not grasp and pull the patient cable to
remove from the SmartMonitor 2.
