Speaker

The SmartMonitor 2 speaker allows you to hear any alarm that sounds during monitoring.

System Lights

The lights across the bottom of the front panel indicate if the SmartMonitor 2 is working properly:
Light Indicates
Power The power to the SmartMonitor 2 is on.
Charger The power cord/battery charger is on and plugged into the SmartMonitor 2.
The battery power is low and needs to be charged.
Low battery
Memory full The SmartMonitor 2 memory is full or almost full.
Loose lead An electrode, cable, or lead wire connection is loose at one of the plug-in-ports or the
electrodes are not making good contact with the patient's skin.

Side Panel Features

Self-Test Connector

You use the Self-Test Connector when performing a Functional Self-Test to make sure the lead wires, patient cable and
SmartMonitor 2 are working properly. See the section, Performing a Functional Self-Test for more information.
LA
Connection
!
RA
Connection
SmartMonitor 2 Features
16
