5.2.3 Stecker X1: 78-poliger SUB-D-Steckverbinder (Buchse) APCI-8008-STP-EVAI

Reihe 1 Pins 1-20
1 Puls+ CH1
2 CHA+ CH1
3 Puls+ CH2
4 CHA+ CH2
5 Puls+ CH3
6 CHA+ CH3
7 Puls+ CH4
8 CHA+ CH4
9 Puls+ CH5
10 CHA+ CH5
11 Puls+ CH6
12 CHA+ CH6
13 D-Inp 01
14 D-Inp 05
15 D-Inp 09
16 D-Inp 13
17 (Out 01)
18 AIN6– (Out 05)
19 AIN2–
20 GND
-H
ANDBUCH
Reihe 2 Pins 21–39
21 Puls– CH1
22 CHA– CH1
23 Puls– CH2
24 CHA– CH2
25 Puls– CH3
26 CHA– CH3
27 Puls– CH4
28 CHA– CH4
29 Puls– CH5
30 CHA– CH5
31 Puls– CH6
32 CHA– CH6
33 D-Inp 02
34 D-Inp 06
35 D-Inp 10
36 D-Inp 14
37 (Out 02)
38 AIN6+ (Out 06)
39 AIN2+
Reihe 3 Pins 40–59
40 Sign+ CH1
41 CHB+ CH1
42 Sign+ CH2
43 CHB+ CH2
44 Sign+ CH3
45 CHB+ CH3
46 Sign+ CH4
47 CHB+ CH4
48 Sign+ CH5
49 CHB+ CH5
50 Sign+ CH6
51 CHB+ CH6
52 D-Inp 03
53 D-Inp 07
54 D-Inp 11
55 D-Inp 15
56 CNC-Ready+ (Out 03) 76 CNC-Ready- (Out 04)
57 AIN5– (res. Out 07)
58 AIN1–
59 res. (+24V)
Reihe 4 Pins 60–78
60 Sign– CH1
61 CHB– CH1
62 Sign– CH2
63 CHB– CH2
64 Sign– CH3
65 CHB– CH3
66 Sign– CH4
67 CHB– CH4
68 Sign– CH5
69 CHB– CH5
70 Sign– CH6
71 CHB– CH6
72 D-Inp 04
73 D-Inp 08
74 D-Inp 12
75 D-Inp 16
77 AIN5+ (res. Out 08)
78 AIN1+
