Technical Data; Spare Parts And Accessories - Aventics LS04 Betriebsanleitung

AVENTICS | LS04/LS04 SW | R412018610–BDL–001–AB | English

12 Technical Data

General
Type (valves)
Sealing principle (valves)
Mounting type (valve system)
Pilot (external, internal)
Stages of expansion
Mounting orientation
Ambient temperature min./max.
1)
Mounting kit for hat rail, see "Spare Parts and Accessories"
Pneumatics
Medium
Max. particle size
Oil content of compressed air
Min./max. medium temperature
Flow rate Qn
Directional control valves
2x3/2
Min./max. working pressure
Min./max. control pressure
1)
2x3/2 available in NC-NC, NO-NO or NO-NC
2)
implemented by
3)
implemented by
Electrical parameters for solenoid coils
Operating voltage
Power consumption per solenoid
Duty cycle
Electrical parameters for LS04 and LS04 SW
Max. total current to GND
Generic emission standard
in accordance with
Generic immunity standard
in accordance with
Protection class according to
EN 60 529/IEC 529
Spool valve, zero overlap
Soft sealing
Screw mounting via 4 through holes
for M4 x 35 or a hat rail EN 60715–
1)
TH 35-7.5/TH 35-15
Using different right end plates, port X
is blocked in case of internal pilot
control
2 to 24 plate valves for
2 to 24 solenoid coils
Any
–10°C/+50°C
Compressed air
5 μm
3 3
0 mg/m –5 mg/m
(AVENTICS oil, VG 32:
part number 8982000010)
–10°C/+50°C
175 l/min – 320 l/min
5/2 5/2 5/3
–0.95 bar/8 bar
3 bar/8 bar
24 VDC (± 10%), from a power
pack with safe isolation according
to EN 61558
0.35 W (incl. LED and protective
circuit)
100%
1 A
EN 61000-6-4: 2002
EN 61000-6-2: 2005
IP20, IP50 in installed condition
with connected
D-Sub plug

13 Spare Parts and Accessories

Blanking plate
Supply plate, ports 1, 3, and 5 open
Supply plate/separation plate, port 1 closed,
3 and 5 open
Supply plate/separation plate, port 1 open,
3 and 5 closed
Separation plate, ports 1, 3 and 5 closed
Supply module
Y push-in fitting
Mounting kit for hat rail
Extension kit for 1 valve position
Extension kit for 2 valve positions
Label panel, 20 pieces
Plate valve replacement seals 10 pieces
Silencer for exhaust air Port R/82/84, Ø 6 mm
Port 3/5, Ø 10 mm
Mating plug with ready- Straight, length 3 m, IP65
made cable
Straight, length 10 m, IP65
Angled, length 3 m, IP20
Angled, length 10 m, IP20
For further information on spare parts, accessories and available valves,
please see our online catalog at www.aventics.com.
14
R422100888
R422100896
R422100897
R422100898
R422100899
R422100900
R412009569
R422100892
R422100890
R422100891
R422100889
R422100895
R412000591
R412000593
R412011244
R412011246
R402000782
R402000783
