Table for Mechanical Seal Adjustment
Pump
SCP 50-220 HA
SCP 50-180 HA
SCP 50-340 HA
SCP 50-340 DS
SCP 65-390 HS
SCP 80-230 HA
SCP 80-200 HA
SCP 80-380 DS
SCP 80-340 HA
SCP 80-360 DS
SCP 100-270 HA
SCP 100-280 HA
SCP 100-360 HA
SCP 100-400 HA
SCP 100-410 DS
SCP 125-290 HA
SCP 125-330 HA
SCP 125-440 HA
SCP 125-470 HA
SCP 125-460 DS
SCP 150-290 HA
SCP 150-390 HA
SCP 150-350 HA
SCP 150-440 HA
SCP 150-580 HA
SCP 150-530 HA
SCP 150-460 DS
SCP 200-310 HA
SCP 200-320 HA
SCP 200-370 HA
SCP 200-360 HB
9.5.4 Re-assembly of the pump (Mechanical seal
version pump)
For assembling mechanical seal version pump fol-
low the same procedure as done for gland pack
version pump. Difference in assembly of mechani-
cal seal pump is as follows:
Reassembly of mechanical seal is as follows:
• After placing the top half casing(1) at its position
and tightening the studs(29)
• Slide in the gland plate(15) at its position and tight
its studs
• Now fix the flushing tubes(35) to the mechanical
seal gland plate(15)
• Rest procedure is same as explained above for
gland pack version pump
72
Mech.seal Distance on the shaft
Diam. (L)
(Ø dw)
MG1
28 mm 16.5 mm 26 mm
32 mm 17.5 mm 26 mm
32 mmq 17.5 mm 26 mm
38 mm 20 mm 26 mm
38 mm 20 mm 26 mm
38 mm 20 mm 26 mm
38 mm 28 mm 26 mm
42 mm 20 mm N.A.
38 mm 20 mm 26 mm
48 mm 20 mm 26 mm
38 mm 20 mm 26 mm
38 mm 20 mm 26 mm
38 mm 20 mm 26 mm
38 mm 20 mm 26 mm
50 mm 23.5 mm 23.5 mm
50 mm 20.5 mm 27.5 mm
38 mm 20 mm 26 mm
38 mm 20 mm 26 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
50 mm 20.5 mm 27.5 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
60 mm 28 mm 32.5 mm
Pump
M74
SCP 200-390 HA
SCP 200-440 HA
SCP 200-460 HA
SCP 200-550 HA
SCP 200-480 HA
SCP 200-560 HA
SCP 200-660 DV
SCP 250-250 HA
SCP 250-390 HA
SCP 250-360 HA
SCP 250-450 HA
SCP 250-570 HA
SCP 250-700 DV
SCP 250-740 DV
SCP 300-330 HB
SCP 300-380 HA
SCP 300-400 HA
SCP 300-490 HA
SCP 300-570 HA
SCP 300-660 DV
SCP 350-500 HA
SCP 350-470 HA
SCP 400-540 HA
SCP 400-480 HA
SCP 400-550 HA
SCP 400-710 HA
SCP 400-660 DV
NOTE:
While assembling stainless steel component,
molybdenum-disulphide paste should be applied
to prevent galling / seizure and also to facilitate
easy removal in future.
NOTE:
Change the gasket each time when the pump is
opened.
Mech.seal Distance on the shaft
Diam. (L)
(Ø dw)
MG1
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
95 mm 36 mm 42.8 mm
95 mm 36 mm 42.8 mm
50 mm 20.5 mm 42.8 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
95 mm 36 mm 42.8 mm
95 mm 36 mm 42.8 mm
100 mm 37 mm 42.8 mm
100 mm 37 mm 42.8 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
75 mm 30 mm 37 mm
95 mm 36 mm 42.8 mm
95 mm 36 mm 42.8 mm
115 mm N.A. 42 mm
95 mm 36 mm 42.8 mm
95 mm 36 mm 42.8 mm
95 mm 36 mm 42.8 mm
95 mm 36 mm 42.8 mm
100 mm 37 mm 42.8 mm
100 mm 37 mm 42.8 mm
130 mm N.A. 42 mm
