Xclear automatic "stand alone" valve
Drawing 1
Drawing 2
8
Drawing 3
EN A M4 socket-head screws (Allen screw) (2 pieces)
B Cable gland
C Top cover
D Nut
E Print with connectors
F Threaded end for the print attachment
G Motor + gear box
H M5 x 40 bolt (4 pieces)
I Motor mounting piece
J Button head screw
K Nut (2 pieces)
L Screw for the micro switch (3 pieces)
M Micro switch (3 pieces)
N Plastic cam
O Base for the micro switch
P O-ring large
Q O-ring small
R Cylinder rotor seal
S Sealing rubber
T Phillips screw (2 pieces)
U Sealing rubber insert
V O-ring small
W 3-way valve housing
W 2-way valve housing
X M5 Nut (4 pieces)
