Figure 12-3 Size 7 and 8 power and ground connections (size 7 shown)
On size 7 and 8, the supply and motor ground connections are made using the M8 studs located by
the supply and motor connection terminals. Refer to Figure 12-3.
16
Input connections
Mains
Supply
Supply
ground
L1
Fuses
Optional
line reactor
Optional
EMC filter
L1 L2
PE +DC -DC
8
Output connections
U V W
Motor
Optional ground
connection
L2 L3
L3
+DC BR
Thermal
Optional
overload
braking
protection
resistor
device
