AKM2G Instructions | 9 Connector Pinout
9.4 Connector code J: AKM2G7
9.4.1 Power & SFD3 AKM2G7 (Feedback code CA)
9.4.2 Power & DSL AKM2G7 (Feedback code GU)
244
Kollmorgen | kdn.kollmorgen.com | May 2019
Pin Function Pin Function
U
U
5 BR +
V
V
8 BR -
W
W
6 SFD +
PE
7 SFD -
9
N/C
Pin Function Pin Function
U
U
V V
W
W
N –
1
BR+
2 BR–
PE
E1 DSL+
E2
DSL–
Pin Function Pin Function
–
1
Up
2 0 V
3
Data
4 Data
5
Clock
6 Clock
