7.6.2 Technical Data AKM2G-63
U Parameter
N
Max. Rated Equivalent Line Voltage
Max. Continuous Torque for ∆ T winding = 100°C
(1)(2)(4)
Max. Continuous Current for ∆ T winding = 100°C
(1)(2)(4)
Max. Continuous Torque for ∆ T winding = 60°C
(2)(4)
Max. mechanical speed (5)
Peak Torque (1)(2)(4)
Peak Current
120 V Rated Torque (speed) (1)(2)(4)
AC
Rated Speed
Rated Power (speed) (1)(2)(4)
240 V Rated Torque (speed) (1)(2)(4)
AC
Rated Speed
Rated Power (speed) (1)(2)(4)
400 V Rated Torque (speed) (1)(2)(4)
AC
Rated Speed
Rated Power (speed) (1)(2)(4)
480 V Rated Torque (speed) (1)(2)(4)
AC
Rated Speed
Rated Power (speed) (1)(2)(4)
Torque Constant (1)
Back EMF Constant (6)
Motor Constant (1)
Resistance (line-line) (6)
Inductance Q-Axis (line-line)
Inductance D-Axis (line-line)
Inductance Saturation Current
Maximum Demagnetization Current
AKM2G Instructions | 7 Technical Data
Tolerance Symbol
Electrical data
Max V bus
Nom Tmc
Nom Imc
Nom Tmc
Nom Nmax
Nom Tp
Nom Ip
Trtd
Nrtd
Prtd
Trtd
Nrtd
Prtd
Trtd
Nrtd
Prtd
Trtd
Nrtd
Prtd
+/- 10% Kt
+/- 10% Ke
Nom Km
+/- 10% Rm
Lqll
Ldll
Lisat
Midpeak
Kollmorgen | kdn.kollmorgen.com | May 2019
Units AKM2G
63H 63K 63M 63N
V ac 480 480 480
Nm 21.7 21.5 21.4 21.4
ib-in 192 190 189
Arms 6.11 9.79 15.2 16.8
Nm 17.0 16.9 16.9 16.9
lb-in 150 150 149
rpm 6000 6000 6000 6000
Nm 55.1 54.7 54.5 54.5
lb-in 487 484 482
Arms 18.3 29.4 45.5 50.5
Nm 20.9 20.7
lb-in 185
rpm 1000 1100
kW 2.19 2.39
Hp 2.93 3.20
Nm 21.5 20.5 19.2 18.7
lb-in 191 181 170
rpm 750 1300 2100 2300
kW 1.69 2.79 4.21 4.51
Hp 2.27 3.74 5.65 6.05
Nm 20.6 18.9 15.6 14.1
lb-in 182 167 138
rpm 1300 2200 3600 4100
kW 2.80 4.35 5.88 6.07
Hp 3.75 5.84 7.89 8.14
Nm 20.1 17.8 12.8
lb-in 178 158 114
rpm 1600 2700 4500
kW 3.37 5.03 6.05
Hp 4.52 6.75 8.12
Nm/Arms 3.56 2.20 1.41 1.27
lb-in/Arms 31.5 19.5 12.5 11.3
Vrms/krpm 240 148.8 95.5 86.0
Nm/√W 1.66 1.65 1.65 1.65
lb-in/√W 14.7 14.6 14.6 14.6
Ω 3.07 1.184 0.491 0.398
mH 51.6 19.8 8.2
mH TBD TBD TBD TBD
Arms 175 282 439
Arms TBD TBD TBD TBD
400
189
149
482
183
166
125
6.6
488
201
