8.1 Dimensions/Radial Forces AKM2G2 (Ax flanges)

Model Non-Brake
X Ref
Resolver /
mm inch mm
AKM2G- 90.75 3.573 111.15 4.376 118.15 4.652 129.75 5.108 150.15 5.911 157.15 6.187
21
AKM2G- 110.00 4.331 130.40 5.134 137.40 5.409 149.00 5.866 169.40 6.669 176.40 6.945
22
AKM2G- 129.25 5.089 149.65 5.892 156.65 6.167 168.25 6.624 188.65 7.427 195.65 7.703
23
AKM2G- 148.50 5.846 168.90 6.650 175.90 6.925 187.50 7.382 207.90 8.185 214.90 8.461
24
L Max
DSL / EnDat
SFD3 2.2
inch mm inch mm inch mm
AKM2G Instructions | 8 Dimension drawings
Brake
X Ref L Max.
Resolver /
SFD3 EnDat 2.2
inch mm
Kollmorgen | kdn.kollmorgen.com | May 2019
D - Connector
Feedback
DSL / SFD3 DSL &
EnDat
inch
42.8 44.1
